Shining 3D
FreeScan UE Pro 2
The wireless Shining 3D FreeScan UE Pro2 handheld laser scanner delivers metrology accuracy down to 0.02 mm with three blue laser modes.
C000003SKU17000 gWeighthardwareProduct type
01 / 06
Shining 3D FreeScan UE Pro 2
The wireless Shining 3D FreeScan UE Pro2 handheld laser scanner delivers metrology accuracy down to 0.02 mm with three blue laser modes.
€19,999.00
excl. VAT · plus shipping
Available at short noticeDelivery date is confirmed after ordering.
Bonus
€338.00 value at no extra cost
Video Workflow LibraryIncluded in the packageIncluded€249.00
FreeScan, EinScan & Einstar PackageIncluded in the packageIncluded€89.00
Is this the right system for your application?We review your application, component and workflow with you.
or
All details
Product information
The Shining 3D FreeScan UE Pro2 is a cutting-edge wireless laser handheld 3D scanner designed for high-precision metrology applications such as inspection, reverse engineering, and large-scale scanning. It features ultra-fast data capture at up to 3,460,000 points per second and delivers remarkable accuracy down to 0.02 mm, making it ideal for intricate and detailed scanning tasks.
This scanner offers three versatile laser scan modes using eye-safe blue lasers: high-speed mode with 50 laser lines for capturing large areas rapidly; detailed mode with 7 parallel laser lines for fine detail and small features; and deep pockets mode with a single laser line specifically designed to access holes, edges, and recesses. Its integrated wireless module frees users from cable constraints while embedded computing accelerates data processing without overloading connected computers.
The FreeScan UE Pro2 achieves consistent volumetric accuracy, enhanced by built-in video photogrammetry and a patented binocular system for markerless tracking, suitable for indoor and outdoor environments. Its robust operational range and environmental resistance make it highly versatile in different working conditions. Certified to international standards and packaged with powerful software tools, this scanner integrates seamlessly into professional workflows.
Features
Three Laser Scan Modes
High-speed (50 lines), detailed (7 lines), and deep pockets (1 line) for versatile application needs
Fast Data Capture
High frame rate up to 180 FPS and 3,460,000 points per second scanning speed
High Accuracy
Up to 0.02 mm accuracy with volumetric precision enhanced by photogrammetry
Environmental & Software Compatibility
Operates in varied conditions with software support for STL, OBJ, and CAD exports
Wireless Operation
Cable-free scanning with embedded computing for efficient data processing
Technical product details
SKUC000003
EAN6970163081816
Weight17000 g
Measurement
Accuracy0.02 mm + 0.015 mm/m (photogrammetry enhanced)
Rangeup to 600 mm field of view, 360 mm scan depth
The Shining 3D FreeScan UE Pro2 is a cutting-edge wireless laser handheld 3D scanner designed for high-precision metrology applications such as inspection, reverse engineering, and large-scale scanning. It features ultra-fast data capture at up to 3,460,000 points per second and delivers remarkable accuracy down to 0.02 mm, making it ideal for intricate and detailed scanning tasks.
This scanner offers three versatile laser scan modes using eye-safe blue lasers: high-speed mode with 50 laser lines for capturing large areas rapidly; detailed mode with 7 parallel laser lines for fine detail and small features; and deep pockets mode with a single laser line specifically designed to access holes, edges, and recesses. Its integrated wireless module frees users from cable constraints while embedded computing accelerates data processing without overloading connected computers.
The FreeScan UE Pro2 achieves consistent volumetric accuracy, enhanced by built-in video photogrammetry and a patented binocular system for markerless tracking, suitable for indoor and outdoor environments. Its robust operational range and environmental resistance make it highly versatile in different working conditions. Certified to international standards and packaged with powerful software tools, this scanner integrates seamlessly into professional workflows.
Features
Three Laser Scan Modes
High-speed (50 lines), detailed (7 lines), and deep pockets (1 line) for versatile application needs
Fast Data Capture
High frame rate up to 180 FPS and 3,460,000 points per second scanning speed
High Accuracy
Up to 0.02 mm accuracy with volumetric precision enhanced by photogrammetry
Environmental & Software Compatibility
Operates in varied conditions with software support for STL, OBJ, and CAD exports
Wireless Operation
Cable-free scanning with embedded computing for efficient data processing
Technical product details
SKUC000003
EAN6970163081816
Weight17000 g
Measurement
Accuracy0.02 mm + 0.015 mm/m (photogrammetry enhanced)
Rangeup to 600 mm field of view, 360 mm scan depth
Fields of application
Where FreeScan UE Pro 2 is used
Industries
Applications
Why Scankraft?
We test every scanner ourselves before selling it.
You receive more than a device—you receive a field-tested solution matched to your measurement task.
