Shining 3D
EinScan Pro HD
The Shining 3D EinScan Pro HD delivers high-precision 3D scanning for challenging surfaces using flexible handheld and fixed scanning modes.
SHINING-3D-EINSCAN-PRO-HDSKU1VariantshardwareProduct type
01 / 03
Shining 3D EinScan Pro HD
The Shining 3D EinScan Pro HD delivers high-precision 3D scanning for challenging surfaces using flexible handheld and fixed scanning modes.
€7,199.00
excl. VAT · plus shipping
Available at short noticeDelivery date is confirmed after ordering.
Bonus
€338.00 value at no extra cost
Video Workflow LibraryIncluded in the packageIncluded€249.00
FreeScan, EinScan & Einstar PackageIncluded in the packageIncluded€89.00
Is this the right system for your application?We review your application, component and workflow with you.
or
All details
Product information
The Shining 3D EinScan Pro HD is a professional-grade handheld 3D scanner that offers exceptionally high accuracy and detailed point cloud capture, designed for applications such as reverse engineering, product design, manufacturing, and digital archiving. With a modular design, it supports both handheld (HD and Rapid modes) and fixed scanning, ensuring versatility and optimal results for various objects ranging from small parts to large-scale items.
Equipped with structured light technology utilizing an LED projector and dual cameras, the EinScan Pro HD efficiently captures high-resolution scans with point distances as fine as 0.2 mm. It excels at scanning challenging surfaces, including dark, black, or metallic objects, thanks to enhanced lighting projection and advanced algorithms. The scanner operates at high speeds, acquiring up to 3 million points per second in handheld mode and completing single fixed scans in under 0.5 seconds.
The bundled EXScan software streamlines the scanning workflow with features like automatic alignment, noise removal, hole filling, and texture enhancement, making the creation of high-quality 3D models seamless and efficient. Optional add-ons like the Color Pack provide full-color texture scanning, while the Industrial Pack includes a tripod and turntable for precise fixed scanning.
Features
High Accuracy
Up to 0.04 mm accuracy in fixed mode and 0.045 mm in handheld HD mode for precise measurement.
Multi-Mode Scanning
Supports handheld HD, handheld Rapid, and fixed scan modes to adapt to different scanning needs and objects.
Fast Scanning Speed
Captures up to 3,000,000 points per second in handheld mode, enabling quick data acquisition.
Material Compatibility
Effective scanning of dark, black, and metal surfaces using advanced lighting and algorithms.
Comprehensive Software
Includes EXScan software with automatic alignment, noise removal, hole filling, and optional texture scanning with the Color Pack.
Technical product details
SKUSHINING-3D-EINSCAN-PRO-HD
Measurement
Accuracy0.04 mm (fixed mode), 0.045 mm (handheld HD mode)
Range209 x 160 mm ~ 310 x 240 mm (single scan range)
The Shining 3D EinScan Pro HD is a professional-grade handheld 3D scanner that offers exceptionally high accuracy and detailed point cloud capture, designed for applications such as reverse engineering, product design, manufacturing, and digital archiving. With a modular design, it supports both handheld (HD and Rapid modes) and fixed scanning, ensuring versatility and optimal results for various objects ranging from small parts to large-scale items.
Equipped with structured light technology utilizing an LED projector and dual cameras, the EinScan Pro HD efficiently captures high-resolution scans with point distances as fine as 0.2 mm. It excels at scanning challenging surfaces, including dark, black, or metallic objects, thanks to enhanced lighting projection and advanced algorithms. The scanner operates at high speeds, acquiring up to 3 million points per second in handheld mode and completing single fixed scans in under 0.5 seconds.
The bundled EXScan software streamlines the scanning workflow with features like automatic alignment, noise removal, hole filling, and texture enhancement, making the creation of high-quality 3D models seamless and efficient. Optional add-ons like the Color Pack provide full-color texture scanning, while the Industrial Pack includes a tripod and turntable for precise fixed scanning.
Features
High Accuracy
Up to 0.04 mm accuracy in fixed mode and 0.045 mm in handheld HD mode for precise measurement.
Multi-Mode Scanning
Supports handheld HD, handheld Rapid, and fixed scan modes to adapt to different scanning needs and objects.
Fast Scanning Speed
Captures up to 3,000,000 points per second in handheld mode, enabling quick data acquisition.
Material Compatibility
Effective scanning of dark, black, and metal surfaces using advanced lighting and algorithms.
Comprehensive Software
Includes EXScan software with automatic alignment, noise removal, hole filling, and optional texture scanning with the Color Pack.
Technical product details
SKUSHINING-3D-EINSCAN-PRO-HD
Measurement
Accuracy0.04 mm (fixed mode), 0.045 mm (handheld HD mode)
Range209 x 160 mm ~ 310 x 240 mm (single scan range)
